GRIGGIO GF 21 - TABLE 5 SPINDLES UNIT PARTS

TABLE 5 SPINDLES UNIT
GRIGGIO S.p.A.
WOODWORKING MACHINERY
38
Pos. Code 21G Code 27G Part name Quantity
1 36000047 36000047
Spiral stop support
1
2 00018314 00018314
VCCE-5931 M16X40
2
3 36000043 36000043
Spiral washer
1
4 00018524 00018524
r-cild M16
4
5 36000042 36000042
Spiral spigot
1
6 36000045 36000045
Lens support
1
7 00018523 00018523
r-cild M 12
4
8 00018403 00018403
V-te M 12x35
4
9 00018522 00018522
r-cild M 10
1
10 00018313 00018313
VCCE-5931 M 10x110
1
11 36000044 36000044
Plexiglas index
1
12 00003960 00003960
Counter
1
13 00003942 00003942
Botecoplast Lifting crank 216-80
1
14 36222046 36222046
Depth spiral stop
1
15 36222097 36222097
G-type Spiral plate
1
16 00015206 00015206
Drills feed cylinder
1
17 00018315 00018315
VCCE-5931 M 16x100
2
18 36222051 36222051
Cross beam for hoisting screw (G)
1
19 36000050 36000050
Hoisting screw
1
20 36000009 36000009
Head support
1
21 36000048 36000048
Vertical guide shaft
2
22 00003934 00003934
Boteco 522-104 M10
1
23 36000049 36000049
Horizontal slide shaft
2
24 49900048 49900048
Back shaft contrast
2
25 00004380 00004380
s-el 4x26
1
26 36000052 36000052
Head-supporting plate
1
27 36000053 36000053
Rubber washer
1
28 36000111 36000111
Cylinder shaft extension
1
29 36000124 36000124
Spiral washer
1
30 40000003 40000003
Sintered bush
2
31 00000213 00000213
LI-PIA 5X5X10
1
32 00018312 00018312
V-TCEI m 10X60
1
33* 00018455 00018455
G-EI M 5X6
1
34 00018419 00018419
V-tspei M 4x16
1
35 00003456 00003456
Ring INA AS 1730
4
36 00003455 00003455
Bearing INA AXK1730
2
37 00018310 00018310
V-tcei M 8x160
4
38 00003922 00003922
Release lever KRP-63 M8 L20
2
39 00005047 00005047
Plain bearing PAP 4020P10
8
40 00000168 00000168
Self-locking ring nut
1
41 00018521 00018521
r-cild M 8
1
42 00018501 00018501
D-en M 8
1
