Grill'D Aurora - Technical Data

35
Specifications UOM
Aurora mini Aurora 160 Aurora 160 TRIO Aurora 180
Short Long Short Long Window Short Long Window Short Long Window
Steam room volume m
3
6-12 6-16 6-16 8-18
Heater flue outlet connection diameter mm 115 115 115 115
Mass of stones in the stone heater kg max 25 40 40 30 Stone size mm 70-150 70-150 70-150 70-150
Maximum firewood length mm 320 390 390 390
Firewood diameter mm 80-150 80-150 80-150 80-150
Mass kg 30 32 44 46 61 58 60 75 49 51 66
Width mm 390 390 460 460 650 460 460 650 460 460 650
Height mm 670 670 785 785 785 1430 1430 1430 785 785 785
Depth mm 485 605 615 725 750 615 725 750 615 725 750
Fuel - Wood Wood Wood Wood
Safe distances to combustible materials
From top (from the
connection)
mm
1000 1000 1000 1000
From the side 500 500 500 500
From the back 500 500 500 500
From the front 800 800 800 800
Table 1. Technical data Note: heater dimensions are specified in Appendix 1
