IMPORTANT! Familiarize yourself with the manufacturer’s detailed instrucons on the safe
distances and installaon of steel chimney elements, as well as the water tank.
Some installaon opons are depicted in Figure 5.
3.2.2. Heater connection to a steel chimney
Steel chimneys can be used for ue gas withdrawal. As a rule, it consists of separate modules
that can be coupled with each other, and that form a single duct for ue gas withdrawal.
Chimneys can be installed directly from the heater through the ceiling and roof, or at an
angle through the wall.
If you plan to use a heater rack, for example, then take into account the height of the heater
together with the rack when preparing the hole for passage of the pipe through the wall.
The procedure for installing the pipe at an angle:
1. Install the heater on the place of permanent operaon.
2. Install a water tank, if any. Keep in mind the requirements of its operaons manual.
3. A valve can be installed on the connecng pipe, if addional adjustment of dra is
necessary. Install, if any.
4. Install all the necessary components of the outside chimney.
5. Insert the connecng pipe into the outside chimney.
6. Connect the heater with the pipe inserted into the outside chimney.
7. Ensure that all the pipe connecons and the heater connecon are reliable.
Note: when installing the chimney from the heater directly through the ceiling and roong
system, all the elements are installed consecuvely.
Note: when applying additional vertical load on the heater structure, such as: instal
ling an
additional volume of stones, installing a chimney, installing a water tank, etc., the maximum
permissible load shall be considered. It shall be equivalent to the sum of a filled water tank with
a volume of 70 l max, and one heat-insulated chimney module with a length of one meter.
Use special unloading support plaorms to reduce load, when installing a steel chimney. The
mass of the vercal part of the chimney supported by the heater, shall not be greater than
the maximum permissible one. Further, you need to install an unloading support plaorm
and using it, connue the chimney installaon.
IMPORTANT! Familiarize yourself with the manufacturer’s detailed instrucons on the safe
distances and installaon of steel chimney elements, as well as the water tank.
IMPORTANT! If there is a protecve shield around the stone heater, the chimney insulaon
shall start at the level of the top edge of the shield or lower.
Some installaon opons are depicted in Figure 6.
4. WARRANTY
The warranty period for the Product is 12 months from the date of purchase by the
Consumer, but not more than 24 months from the date of shipment of the Product to the
Dealer, with the lled-in marks on the last page of this manual, namely: the date of sale, the
seller’s signature, the store’s stamp.The date of sale must be conrmed by a check or other
document.
IMPORTANT! The Manufacturer disclaims warranty liability in the absence of a store stamp.
Household usage: the service life of products while meeng the requirements of the
