Model G0621X (Mfd. Since 07/17)
-51-
READ ELECTRICAL SAFETY
ON PAGE 45!
Wiring Diagram
REWIRE
MOTOR
220V, 3-PH
Ground
POWER
SWITCH
(from behind)
MOTOR
SWITCH
SPEED DIAL
(from behind)
INVERTER/CONTROLLER BOX
START
STOP
Tc2
Ta2
Ta1
Tb1
Tc1
The motor wiring shown here is
current at the time of printing;
however, always use the diagram on
the inside of junction box cover
when rewiring your motor.
Hot
Hot
Ground
6-15 Plug
(As Recommended)
220V
Single-Phase
Power
220
VAC
G
SLOW
12V
Vin
GND
Iin
FM+
AM+
Y2
Y1
CME
X4
X3
X2
X1
X6
CCM
X5
REV
COM
FWD
RHYMEBUS
RM5G-2001
KP-203
1HP 1-PH
W
VUPRN-P+
S/NR/L
3
2
1
