Grizzly G0621X User Manual

Model G0621X (Mfd. Since 07/17)
-53-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0621X001 BODY 44 P0621X044 SHAFT
2 P0621X002 PHLP HD SCR 10-24 X 3/4 45 P0621X045 BALL BEARING 6004 ZZ
3 P0621X003 CONTROLLER COVER PLATE 46 P0621X046 BLADE TENSION SCALE
4 P0621X004 HEX NUT 10-24 47 P0621X047 HEX NUT 5/16-18
5V2 P0621X005V2 INVERTER RHYME RM5G 1PH V2.10.16 48 P0621X048 KNOB 5/16-18 X 2
6 P0621X006 PHLP HD SCR 1/4-20 X 1/2 49 P0621X049 STRAIN RELIEF
7 P0621X007 FLAT WASHER 1/2 50 P0621X050 POWER CORD
8 P0621X008 TENSION NUT 51 P0621X051 MOTOR CORD
9 P0621X009 BLADE TENSION POINTER 52 P0621X052 KNOB
10 P0621X010 COMPRESSION SPRING 53 P0621X053 CAP SCREW 1/4-20 X 3/4
11 P0621X011 BLADE TENSION HANDLE 54 P0621X054 ADJUSTMENT SLEEVE
12 P0621X012 SPECIAL WASHER 55 P0621X055 HEX NUT 3/4-10
13 P0621X013 UPPER WHEEL BRACKET 56 P0621X056 BEARING HOUSING
14 P0621X014 HEX BOLT M8-1.25 x 110 57 P0621X057 PIN 6MM
15 P0621X015 UPPER WHEEL SHAFT 58 P0621X058 FLANGE BOLT 5/16-18 X 1-1/2
16 P0621X016 BALL BEARING 6202 ZZ 59 P0621X059 COVER
17 P0621X017 INT RETAINING RING 35MM 60 P0621X060 HEX NUT 5/8-11
18 P0621X018 UPPER WHEEL-GRIZZLY HEADS 61 P0621X061 FLAT WASHER 5/8
19 P0621X019 TIRE 62 P0621X062 FLAT WASHER 3/8
20 P0621X020 FLAT WASHER 1/4 63 P0621X063 HEX BOLT 3/8-16 X 2-1/2
21 P0621X021 LOCK WASHER 1/4 64 P0621X064 MOTOR 1.25HP, 220V, 3-PHASE
22 P0621X022 HEX BOLT 1/4-20 X 3/8 64-1 P0621X064-1 JUNCTION BOX REAR COVER
23 P0621X023 SAW BLADE 108" X 3/8" 6-TPI HOOK 64-2 P0621X064-2 JUNCTION BOX FRONT COVER
24 P0621X024 HINGE PIN 64-3 P0621X064-3 PHLP HD SCR 10-24 X 1/4
25 P0621X025 UPPER WHEEL COVER 64-4 P0621X064-4 3-CIRCUIT TERMINAL BLOCK
26 P0621X026 LOCK WASHER 1/2 65 P0621X065 ADJ HANDLE 3/8-16 X 1
27 P0621X027 HEX NUT 1/2-20 66 P0621X066 KEY 5 X 5 X 30
28 P0621X028 PHLP HD SCR M3-.5 X 18 67 P0621X067 HEX NUT 3/8-16
29 P0621X029 INVERTER/CONTROLLER BOX 68 P0621X068 DUST PORT 2.5"
30 P0621X030 SPEED DIAL 69 P0621X069 V-BELT A28
31 P0621X031 SWITCH W/LARGE STOP 70 P0621X070 EXT RETAINING RING 15MM
32 P0621X032 KEY 5 X 5 X 25 71 P0621X071 MOTOR PULLEY
33 P0621X033 SET SCREW 1/4-20 X 3/8 72 P0621X072 PULLEY
34 P0621X034 HEX NUT M8-1.25 73 P0621X073 BRUSH
35 P0621X035 PHLP HD SCR 1/4-20 X 1/2 74 P0621X074 HEX NUT 1/4-20
36 P0621X036 LOWER WHEEL COVER 75 P0621X075 SWITCH COVER
37 P0621X037 CAP SCREW 1/4-20 X 3/4 76 P0621X076 PHLP HD SCR M4-.7 x 18
38 P0621X038 HEX NUT 3/4-10 (LH) 77 P0621X077 PHLP HD SCR M4-.7 X 6
39 P0621X039 LOWER WHEEL-GRIZZLY HEADS 78 P0621X078 FLAT WASHER 3/8
41 P0621X041 PULLEY 79 P0621X079 HEX BOLT 1/4-20 X 3/4
42 P0621X042 SHAFT 80 P0621X080 PHLP HD SCR 10-24 X 1/4
43 P0621X043 V-BELT A30 81 P0621X081 HEX NUT 1/4-20
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Main Parts List
