Grizzly G0705 User Manual

-46-
Model G0705 (Mfg. since 09/09)
Neutral
Hot
Ground
110 VAC
5-20 Plug
(As Recommended)
Hot
Hot
Ground
6-15 Plug
(As Recommended)
G
Ground
PE
V2
V1
U2
U1
U2
V1
V2
Z1
W1
Z2
W2
U1
U2
V1
V2
Z1
W1
Z2
W2
U1
To Electrical Box
Start
Capacitor
150 MFD
250 VAC
Run
Capacitor
20 MFD
450 VAC
110V Terminal
Block Jumper
Position.
(Wire positions
are the same for
110V/220V)
To Electrical Box
Cord Rewired for 110V
Motor 220V
G0705 Wiring Diagram
