Model G0705 (Mfg. since 09/09)
-49-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0705001 HEAD CASTING 19 P0705019 DEPTH STOP BLOCK
2 P0705002 DRAWBAR 20 P0705020 PINION SHAFT
3 P0705003 SPINDLE LOCK NUT 21 P0705021 FLAT HD SCR 10-24 X 1/2
4 P0705004 SPINDLE PULLEY 22 P0705022 KEY 7 X 7 X 20
5 P0705005 OUTER BEARING PLATE 23 P0705023 DOWNFEED ASSEMBLY
6 P0705006 CAP SCREW 1/4-20 x 1/2 23-1 P0705023-1 CASE
7 P0705007 SPINDLE TAPER SLEEVE SET 23-2 P0705023-2 WORM SHAFT
7-1 P0705007-1 SPINDLE TAPER SLEEVE 23-3 P0705023-3 BALL BEARING 6202ZZ
7-2 P0705007-2 BALL BEARING 6009ZZ 23-4 P0705023-4 EXT RETAINING RING 15MM
7-3 P0705007-3 SPACER 74MM 23-5 P0705023-5 SPACER 34MM
7-4 P0705007-4 EXT RETAINING RING 41MM 24 P0705024 CAP SCREW 5/16-18 X 3/4
8 P0705008 INT RETAINING RING 80MM 25 P0705025 SLEEVE ASSEMBLY
9 P0705009 RUBBER FLANGE 26 P0705026 COMPRESSION SPRING
10 P0705010 QUILL CLAMP 27 P0705027 LEVER BASE
11 P0705011 QUILL ASSEMBLY 28 P0705028 FEED ADJUST KNOB M10-1.5 X 45
11-1 P0705011-1 SPANNER NUT 29 P0705029 LEVER
11-2 P0705011-2 TOOTHED SPINDLE WASHER 31 P0705031 WORM SHAFT COVER
11-3 P0705011-3 TAPERED ROLLER BEARING 30206 32 P0705032 CAP SCREW 10-24 X 3/8
11-4 P0705011-4 SPINDLE SLEEVE MT#3 33 P0705033 MICRO ADJUST INDICATOR SET
11-5 P0705011-5 TAPERED ROLLER BEARING 30207 35 P0705035 HANDWHEEL ASSEMBLY
11-6 P0705011-6 SPINDLE SHAFT 37 P0705037 TORSION SPRING BASE
11-7 P0705011-7 SPINDLE CUP 39 P0705039 CAP SCREW 10-24 X 3/4
12 P0705012 DRIFT KEY 40 P0705040 TORSION SPRING W/COVER
13 P0705013 CHUCK ARBOR R8-B16 41 P0705041 LOCK WASHER 1/4
14 P0705014 CUTTER ARBOR 42 P0705042 FLAT WASHER 1/4
15 P0705015 DEPTH STOP ASSEMBLY 43 P0705043 LOCK WASHER 1/4
16 P0705016 DEPTH STOP ADJUSTER 44 P0705044 KNOB BOLT M8-1.25 X 12
17 P0705017 CAP SCREW 1/4-20 x 2 45 P0705045 WORM SHAFT
18 P0705018 HEX NUT 1/4-20 46 P0705046 WORM SHAFT BUSHING
Headstock Parts List
