-52-
Model G0705 (Mfg. since 09/09)
Base Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0705201 TABLE 226 P0705226 HEX BOLT 5/16-18 X 1/2
202 P0705202 T-NUT 1/4-20 227 P0705227 GIB SCREW
203 P0705203 TABLE STOP 228 P0705228 STEEL BALL 6MM
204 P0705204 CAP SCREW 1/4-20 X 1/2 229 P0705229 LOCK HANDLE M8-1.25 X 32
205 P0705205 BALL OILER 8MM PRESS-IN 230 P0705230 LOCK HANDLE M8-1.25 X 32
206 P0705206 TABLE HANDWHEEL 231 P0705231 CAP SCREW 5/16-18 X 1
207 P0705207 HANDLE 232 P0705232 CAP SCREW 5/16-18 X 2-1/4
209 P0705209 HANDWHEEL COLLAR 233 P0705233 CROSS HALF NUT
210 P0705210 DOWEL PIN 234 P0705234 BASE
211 P0705211 LEFT FLANGE 235 P0705235 CROSS LEADSCREW ASSEMBLY
212 P0705212 CAP SCREW 5/16-18 X 1 236 P0705236 COLUMN BASE
213 P0705213 LONGITUDINAL HALF NUT 237 P0705237 ELEVATION RACK
216 P0705216 LONGITUDINAL LEADSCREW 238 P0705238 COLUMN CAP
217 P0705217 KNURLED THUMBSCREW M5-.8 X 12 240 P0705240 COLUMN RING
218 P0705218 INDICATOR PLATE 241 P0705241 HEX BOLT 5/8-11 X 2-1/2
219 P0705219 RIVET 2MM 242 P0705242 LOCK WASHER 5/8
220 P0705220 SADDLE 243 P0705243 CAP SCREW 5/16-18 X 3/4
221 P0705221 DUST COVER PLATE 244 P0705244 LOCK WASHER 5/16
222 P0705222 DUST COVER 245 P0705245 DRAIN PLUG
223 P0705223 LONGITUDINAL GIB 246 P0705246 HEX BOLT M10-1.5 X 140
224 P0705224 CROSS GIB 247 P0705247 CABINET ASSEMBLY
225 P0705225 TABLE CENTER STOP
