-50-
Model G0705 (Mfg. since 09/09)
Headstock Parts List (continued)
REF PART # DESCRIPTION REF PART # DESCRIPTION
47 P0705047 ELEVATION ASSEMBLY 79 P0705079 SPEED CHART
48 P0705048 CAP SCREW 1/4-20 X 3/4 80 P0705080 PULLEY IDLER PLATE
49 P0705049 ELEVATION CRANK 81 P0705081 HEX NUT 5/8-11
51 P0705051 CLAMP HANDLE 82 P0705082 FLAT WASHER 5/16
52 P0705052 OUTER QUILL CLAMP 83 P0705083 CAP SCREW 5/16-18 X 1-1/2
53 P0705053 INNER QUILL CLAMP 84 P0705084 IDLER PULLEY
54 P0705054 QUILL CLAMP SPACER 85 P0705085 HEX NUT 5/8-11
55 P0705055 QUILL CLAMP HANDLE 86 P0705086 MOTOR PULLEY SET
56 P0705056 SCREW KEY 88 P0705088 V-BELT A33
57 P0705057 HEX NUT 3/8-16 89 P0705089 V-BELT A39
58 P0705058 COMPRESSION SPRING 90 P0705090 WIRE CLIP
59 P0705059 BELT TENSION PIN 91 P0705091 CAP SCREW 5/16-18 X 5/8
60 P0705060 RUBBER PAD 92 P0705092 MOTOR MOUNT PLATE
61 P0705061 HEX BOLT 5/8-11 X 6 93 P0705093 MOTOR 2HP 110/220V 1-PH
62 P0705062 FLAT WASHER 5/8 93-1 P0705093-1 MOTOR JUNCTION BOX
63 P0705063 HEX NUT 5/8-11 93-2 P0705093-2 S CAPACITOR 150M 250V 1-3/8 X 2-3/4
64 P0705064 HEADSTOCK WRENCH 93-3 P0705093-3 R CAPACITOR 20M 450V 1-5/8 X 3-1/4
65 P0705065 LOCK HANDLE M8-1.25 X 25 93-4 P0705093-4 MOTOR FAN
66 P0705066 FRONT COVER PLATE ASSEMBLY 93-5 P0705093-5 MOTOR FAN COVER
67 P0705067 CAP SCREW 1/4-20 X 1/2 94 P0705094 FLAT WASHER 5/16
68 P0705068 LIMIT PLATE 95 P0705095 HEX BOLT 5/16-18 X 1
69 P0705069 FLAT WASHER 3/16 96 P0705096 HEX NUT 5/16-18
70 P0705070 PHLP HD SCR 5-40 X 1/4 97 P0705097 HEX BOLT 7/16-14 X 3/4
71 P0705071 BELT COVER 98 P0705098 KEY 7 X 7 X 35
72 P0705072 LOWER BELT PLATE 99 P0705099 GUARD BRACKET
74 P0705074 SPINDLE COVER 100 P0705100 CAP SCREW M5-.8 X 8
75 P0705075 CAP SCREW M3-.5 X 16 101 P0705101 CAP SCREW M6-1 X 12
76 P0705076 FLAT WASHER 5/16 102 P0705102 PROTECTIVE PLATE
77 P0705077 HEX BOLT 5/16-18 X 5/8 113 P0705113 CHUCK B16 1-13MM
78 P0705078 CAP SCREW 1/4-20 X 1/2 113-1 P0705113-1 DRL CHK KEY 7.92MM STD 11T SD-15.93MM
