Grizzly G0768 - G0768 Wiring Overview

Model G0768/G0769 (Mfd. Since 8/15)
-89-
G0768 Wiring Overview
JD-013
REV C 120823
Circuit Board
JD-014
REV 091111
Circuit
Board
DC Motor
Speed Control
JYMC-220B-II
Direction Switch
Fuses
and
Plug
Emergency Stop
DRO
RPM Sensor
(Inside)
Potentiometer
Motor (Inside)
110V 10A
Single-Phase
3
⁄4 HP 5250 RPM
