-92-
Model G0768/G0769 (Mfd. Since 8/15)
G0769 Wiring Overview
Mill Motor
(Inside)
110V 10A
Single-Phase
3
⁄4 HP 4800 RPM
Lathe/Mill Selector Switch
Fuses and
Plug
Filter
Circuit Board
Direction
Switch
Potentiometer
Lathe Motor
(Inside)
110V 10A
Single-Phase
3
⁄4 HP 5250 RPM
RPM Sensor
(Inside)
DRO
Emergency Stop
Speed
Control
Circuit Board
