Model G0842 (Mfd. Since 04/18)
-3-
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
For Your Own Safety Read Instruction Manual Before
Operating Lathe
a) Wear eye protection.
b) Do not wear gloves, necktie, or loose clothing.
c) Tighten all locks before operating.
d) Rotate workpiece by hand before applying power.
e) Rough out workpiece before installing on faceplate.
f) Do not mount split workpiece or one containing knot.
g) Use lowest speed when starting new workpiece.
Motor
Bed
Tool Rest
Lock Handle
Tool Rest
Tailstock
Quill
Tool Tray
Cutting Tool
Adjustment
Handwheel
ON/OFF
Switch w/
Disabling Key
Tailstock
Handwheel
Copy Attachment
Handwheels
Cutting
Tool Lock
Handle
Copy
Attachment
Spindle
Headstock
Spindle Speed
Lever
