-6-
Model G0842 (Mfd. Since 04/18)
Machine Data Sheet
The information contained herein is deemed accurate as of 9/19/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2
Model G0842
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0842 WOOD LATHE WITH COPY ATTACHMENT
Product Dimensions:
Weight.............................................................................................................................................................. 155 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................................... 62 x 24 x 48 in.
Footprint (Length x Width)..................................................................................................................... 54 x 18-1/2 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 164 lbs.
Length x Width x Height....................................................................................................................... 60 x 17 x 19 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement............................................................................................................ 110V, Single-Phase, 60Hz
Full-Load Current Rating........................................................................................................................................ 11A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 8 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type.................................................................................................................................... NEMA 5-15
Switch Type.................................................................................................. Paddle Safety Switch w/Removable Key
Motors:
Main
Horsepower............................................................................................................................................. 3/4 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 11A
Speed................................................................................................................................................ 1700 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer .................................................................................................................................. Belt Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Main Specifications:
Operation Information
Swing Over Bed......................................................................................................................................... 14 in.
Swing Over Tool Rest Base....................................................................................................................... 12 in.
Distance Between Centers........................................................................................................................ 37 in.
Max. Distance Tool Rest to Spindle Center........................................................................................... 4-1/2 in.
No of Spindle Speeds..................................................................................................................................... 10
Spindle Speed Range................................................................................................................ 600–2400 RPM
Floor to Center Height......................................................................................................................... 44-5/8 in.
Spindle Information
Spindle Thread Size........................................................................................................................ 1 in. x 8 TPI
Spindle Thread Direction.................................................................................................................. Right Hand
Type of Included Spindle Center............................................................................................................... MT#2
