Model G0939/G0940 (Mfd. Since 12/20)
-29-
3. Install gib over knife, and slightly tighten gib
screws, starting at middle and working your
way to ends by alternating left and right, as
shown in Figure 25.
4.
Press safety latch to disengage cutterhead
lock (see Figure 23), then carefully rotate
cutterhead approximately ¼-turn. Release
safety latch and continue rotating cutterhead
until next knife slot is exposed and safety
latch again engages.
5.
Repeat Steps 2–3 for remaining knives, then
replace dust shroud and dust chute.
12
34
5
6
Figure 25. Gib screw tightening sequence.
Figure 24. Example of installing knife with
magnet.
Beveled Edge Up
Installing Knives
1. DISCONNECT MACHINE FROM POWER!
2. Using included magnets, align knife with two
pins on cutterhead. Be sure knife is oriented
with beveled edge up, as shown in Figure 24.
