Grizzly G0939 User Manual

Model G0939/G0940 (Mfd. Since 12/20)
-49-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G0940 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0940001 CAP 51 P0940051 RETAINER (LEFT)
2 P0940002 CAP SCREW M5-.8 X 25 52 P0940052 CAP SCREW M5-.8 X 16
3 P0940003 FLAT WASHER 5MM 53 P0940053 FLAT WASHER 5MM
4 P0940004 CUTTERHEAD ELEVATION CRANK 54 P0940054 SIDE COVER (LEFT)
5 P0940005 TOP COVER 55 P0940055 COLUMN
6 P0940006 BUTTON HD CAP SCR M6-1 X 12 56 P0940056 LEADSCREW (LEFT)
7 P0940007 FLAT WASHER 6MM 57 P0940057 TABLE CLAMP PLATE (LEFT)
8 P0940008 RETURN ROLLER 58 P0940058 GRANITE TABLE
9 P0940009 ROLLER END CAP 59 P0940059 LEADSCREW (RI GHT)
10 P0940010 HANDLE GRI P 60 P0940060 BUTTON HD CAP SCR M5-.8 X 10
11 P0940011 PHLP HD SCR M5-.8 X 10 61 P0940061 TABLE CLAMP PLATE (RIGHT)
12 P0940012 FLAT WASHER 5MM 62 P0940062 BASE
13 P0940013 CABLE CLAMP 63 P0940063 HEX BOLT M6-1 X 20
14 P0940014 EXT RETAI NI NG RI NG 15MM 64 P0940064 HEX NUT M6-1
15 P0940015 CHAIN 65 P0940065 FLAT WASHER 10MM
16 P0940016 SPROCKET 8T 66 P0940066 CAP SCREW M10-1.5 X 40
17 P0940017 BUSHING 67 P0940067 STEEL BALL 8MM
18 P0940018 SHOULDER SCREW M5-.8 X 35, 6 X 25 68 P0940068 COMPRESSION SPRING
19 P0940019 GEARBOX 69 P0940069 FLAT WASHER 16MM
20 P0940020 CHAIN COVER 70 P0940070 BALL BEARING 6000ZZ
21 P0940021 PINI ON 71 P0940071 BEARING CLAMP PLATE
22 P0940022 BALL BEARING 6203ZZ 72 P0940072 BUTTON HD CAP SCR M5-.8 X 10
23 P0940023 ELEVATION NUT (LEFT) 73 P0940073 FLAT WASHER 10MM
24 P0940024 SET SCREW M5-.8 X 6 74 P0940074 PINION GEAR
25 P0940025 HEADSTOCK 75 P0940075 FLAT WASHER 5MM
26 P0940026 CAP SCREW M5-.8 X 10 76 P0940076 CAP SCREW M5-.8 X 12
27 P0940027 BELT COVER 77 P0940077 EXT RETAINI NG RING 10MM
28 P0940028 ELEVATI ON NUT (UPPER RIGHT) 78 P0940078 CAP SCREW M5-.8 X 12
29 P0940029 PUSH ROD 79 P0940079 SUPPORT CLAMP
30 P0940030 COMPRESSION SPRING 80 P0940080 SHAFT
31 P0940031 CAP SCREW M6-1 X 16 81 P0940081 CAP SCREW M5-.8 X 8
32 P0940032 ELEVATI ON NUT (LOWER RIGHT) 82 P0940082 FLAT WASHER 5MM
33 P0940033 PHLP HD SCR M5-.8 X 10 83 P0940083 EXTENSION TABLE
34 P0940034 LOCK WASHER 5MM 84 P0940084 CAP SCREW M6-1 X 16
35 P0940035 EXT TOOTH WASHER 5MM 85 P0940085 BUSHING
36 P0940036 DEPTH-OF-CUT GAUGE 86 P0940086 LOCK WASHER 6MM
37 P0940037 PHLP HD SCR M4-.7 X 12 87 P0940087 TABLE SUPPORT ARM
38 P0940038 BUTTON HD CAP SCR M5-. 8 X 10 88 P0940088 KNOB BOLT M6-1 X 14, D18 KD
39 P0940039 SET SCREW M5-.8 X 6 89 P0940089 DUST CHUTE
40 P0940040 ROD CLAMP PLATE 90 P0940090 DUST PORT ADAPTER 4"
41 P0940041 MOTOR PIVOT ROD 91 P0940091 GASKET
42 P0940042 PHLP HD SCR M4-.7 X 16 92 P0940092 CAP SCREW M5-.8 X 10
43 P0940043 POINTER 93 P0940093 DUST SHROUD
44 P0940044 BEARING BLOCK COMPRESSION SPRING (LH) 94 P0940094 DUST PLATE
45 P0940045 OUTFEED ROLLER 95 P0940095 TAP SCREW M4.2 X 13
46 P0940046 BEARING BLOCK COMPRESSION SPRING (RH) 96 P0940096 MAGNET
47 P0940047 BEARING BLOCK 97 P0940097 HEX WRENCH 4MM
48 P0940048 RETAINER (RI GHT) 98 P0940098 CAP SCREW M5-.8 X 16
49 P0940049 CAP SCREW M5-.8 X 12 99 P0940099 MOUNTING ARM
50 P0940050 INFEED ROLLER 100 P0940100 SUPPORT BLOCK
