V. PIECE INVENTORY
Take a quick inventory of the parts and put them aside for assembly later.
Since the majority of the shaper is pre-assembled at the factory, there aren’t a lot of items to inven-
tory. You should have the following:
• Shaper Unit
• Miter Gauge
• Spindle and Spacers
• Fence Boards
• Freehand Guard
• Bolt Bag (See below)
• Stand (4 pcs.)
• Adjustable Fence (3 pcs.)
The Model G1026 Bolt Box contains:
Rubber Feet (4)
Hex Bolt M6-1.0x12 (4)
Hex Nut M6-1.0 (4)
Flat Washer
3
/8
" (4)
Carriage Bolt M8-1.25x20 (16)
Nut M8-1.25 (16)
Flat Washer
3
/8" (16)
Slot Head Screws (4)
Flat Washer
5
/16
" (4)
Nut M8-1.25 (4)
The quantities given here are the minimum necessary to do the job; there may be some extra parts.
On the other hand, bolt bags are occasionally shipped from the factory with a nut or bolt missing.
You might consider replacing those items at your local hardware store. It’s not that we’re trying to
cheat you, but if you are short two screws that cost 10¢ apiece, it’s much cheaper to buy locally than
writing or phoning us. Even more, the time saved in shipping will mean that your shaper is ready to
use right away. Of course, if the number of items missing is extensive, or if the missing parts are
more substantial than nuts or bolts, we want to know about it, so we can eliminate problems for
future customers.
- 7 -
