G1035 Heavy-Duty Shaper
-9-
SECTION 4: IDENTIFICATION
Controls & Features
To help you understand the set up and operation
instructions, we recommend that you become
familiar with the basic features of your new
shaper.
Please match up the list below with the letters
in Figure 3 to identify the shaper controls and
features.
A. Cutterhead Guard
B. Hold Down
C. Fence
D. Spindle
E. Elevation Handwheel
F. Spindle Height Scale
G. ON/OFF Reversing Switch
H. Miter Gauge
I. Motor Cover
Figure 3. Model G1035 controls and features.
