BdYZa<&%(*$<&%(*EB[\#H^cXZ)$&%

"*&"

Main Parts List

REF PART # DESCRIPTION REF PART # DESCRIPTION

1 P1035001 STAND (G1035) 27 PN02 HEX NUT 5/16-18

1 P1035P001 STAND (G1035P) 28 PW07 FLAT WASHER 5/16

2A P1035002A MOTOR COVER V2.01.06 (G1035) 29V2 P1035029V2 WOOD FENCE FACE 2-3/4 V2.01.09

2A P1035P002A MOTOR COVER V2.01.06 (G1035P) 30 PFH23 FLT HD SCRW 5/16-18 X 1-1/2

3 PS06 PHLP HD SCR 10-24 X 3/8 31 P1035031 SWITCH BOX (G1035)

4 PB21 HEX BOLT 3/8- 16 X 3/4 31 P1035P031 SWITCH BOX (G1035P)

5 PLW04 LOCK WASHER 3/8 32V2 P1035032V2 FWD/REV ROTARY SWITCH V2.04.10

6 PW02 FLAT WASHER 3/8 33A P1035033A U-SWITCH COVER 4-7/8"T V2.10.02 (G1035)

7 P1035007 TABLE 33A P1035P033A U-SWITCH COVER 4-7/8"T (G1035P)

8 P1035008 OUTER TABLE INSERT 33B PFS04M FLANGE SCREW M4-.7 X 6

9 P1035009 INNER TABLE INSERT 34 P1035034 SWITCH MOUNT BRACKET (G1035)

10 P1035010 BARREL SCREW 7/16-14 X 1/2 34 P1035P034 SWITCH MOUNT BRACKET (G1035P)

11A PFH21 FLAT HD SCRW 10-24 X 3/4 35V2 P1035035V2 MOTOR CORD 14G 5W 30" V2.04.10

12 P1035012 STARTING PIN 36V2 P1035036V2 POWER CORD 14G 3W 56" 5-15 V2.04.10

13A P1026046 LOCK HANDLE 5/16"-18 X 1" 38A PN07 HEX NUT 10-24

14 PW07 FLAT WASHER 5/16 39 PHTEK1 TAP SCREW #6 x 1/2"

15V2 P1035015V2 FENCE MOUNT LH 3/8 V2.01.09 (G1035) 40 P1026041 SCALE

15V2 P1035P015V2 FENCE MOUNT LH 3/8 V2.01.09 (G1035P) 45 PTLW01 EXT TOOTH WASHER #10

17 PCAP14 CAP SCREW 3/8-16 X 1 51 P1035051 STRAIN RELIEF SB8R-1

18 PCAP07 CAP SCREW 5/16-18 X 3/4 52 P1035052 STRAIN RELIEF MGB20-10B

19 P1035019 MAIN FENCE HOUSING (G1035) 53 P1035053 STRAIN RELIEF MGB16-10B

19 P1035P019 MAIN FENCE HOUSING (G1035P) 54 P1035054 SWITCH PADLOCK

19A P1035019A COMPLETE FENCE ASSEMBLY (G1035) 55 P1035055 PADLOCK STORAGE HOOK

19A P1035P019A COMPLETE FENCE ASSEMBLY (G1035P) 56 P1035056 REAR STAND PANEL

20A PSS05 SET SCREW 5/16-18 X 1/4 57 PFS03 FLANGE SCREW 10-24 X 3/8

21 P1035021 KNURLED KNOB 60 P1035060 BOTTOM MOTOR BRACE

22 P1035022 ADJ. SCREW BRACKET (G1035) 61 P1035061 CORD CLAMP PLATE

22 P1035P022 ADJ. SCREW BRACKET (G1035P) 62 PS01 PHLP HD SCR 10-24 X 1/2

23 PW07 FLAT WASHER 5/16 63 PN07 HEX NUT 10-24

24 P1035024 FENCE ADJ SCREW 3/8-16 X 4-1/8 V2.10.00 64 PW07 FLAT WASHER 5/16

25 PSS03 SET SCREW 1/4- 20 X 3/8 65 PN02 HEX NUT 5/16-18

26V2 P1035026V2 FENCE MOUNT RH 3/8 V2.01.09 (G1035) 66 PB07 HEX BOLT 5/16-18 X 3/4

26V2 P1035P026V2 FENCE MOUNT RH 3/8 V2.01.09 (G1035P)
