Grizzly G1035 - Machine Data Sheet

")"
BdYZa<&%(*$<&%(*EB[\#H^cXZ)$&%
0$&+,1('$7$
6+((7
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
02'(/*+36+$3(5
EgdYjXi9^bZch^dch/
Weight.............................................................................................................................................................. 195 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 22 x 25 x 40-1/2 in.
Footprint (Length x Width)............................................................................................................... 17-1/2 x 15-1/2 in.
H]^ee^c\9^bZch^dch/
Type..................................................................................................................................................... Cardboard Box
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 221 lbs.
Length x Width x Height....................................................................................................................... 22 x 24 x 40 in.
Must_Ship_Upright................................................................................................................................................. Yes
:aZXig^XVa/
Power Requirement............................................................................................. 120V or 240V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 120V
Full-Load Current Rating....................................................................................................... 12A at 120V, 6A at 240V
Minimum Circuit Size.......................................................................................................... 15A at 120V, 15A at 240V
Switch................................................................................................................................ Lockable Forward/Reverse
Cord Length............................................................................................................................................................ 6 ft.
Cord Gauge.................................................................................................................................................... 14 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type...................................................................................................................... NEMA 5-15 for 110V
Recommended Plug/Outlet Type................................................................................................ NEMA 6-15 for 220V
Bdidgh/
BV^c
Type................................................................................................................. TEFC Capacitor-Start Induction
Horsepower............................................................................................................................................. 1.5 HP
Phase............................................................................................................................................ Single-Phase
Amps....................................................................................................................................................... 12A/6A
Speed................................................................................................................................................ 3450 RPM
Power Transfer .................................................................................................................................. Belt Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
BV^cHeZX^[^XVi^dch/
DeZgVi^dc>c[d
Max. Cutter Height....................................................................................................................................... 2 in.
Max. Cutter Dia............................................................................................................................................ 5 in.
Spindle Sizes..................................................................................................................................... 1/2, 3/4 in.
Spindle Lengths........................................................................................................................... 2-3/4, 3-1/2 in.
Exposed Spindle Length........................................................................................................................ 3-1/8 in.
Spindle Cap Under The Nut.............................................................................................................. 2, 2-1/2 in.
Spindle Speeds.................................................................................................................... 7000, 10,000 RPM
Spindle Travel.............................................................................................................................................. 3 in.
Spindle Openings.................................................................................................................... 1-1/4, 3-1/2, 5 in.
MODEL G1035/G1035P 1-1/2 HP SHAPER
