The information contained herein is deemed accurate as of 5/25/2009 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2Model G7944
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G7944 12 SPEED HEAVY-DUTY 14" FLOOR DRILL
PRESS
Product Dimensions:
Weight.............................................................................................................................................................. 155 lbs.
Length/Width/Height............................................................................................................................. 24 x 14 x 64 in.
Foot Print (Length/Width)............................................................................................................................. 18 x 11 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 171 lbs.
Length/Width/Height............................................................................................................................. 56 x 20 x 10 in.
Electrical:
Switch.................................................................................................................. Paddle On/Off with Safety Lock Tab
Switch Voltage...................................................................................................................................................... 110V
Cord Length...................................................................................................................................................... 8-1/2 ft.
Cord Gauge....................................................................................................................................................16 gauge
Minimum Circuit Size........................................................................................................................................ 15 amp
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................3/4 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps...............................................................................................................................................................9A
Speed.................................................................................................................................................1720 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Construction
Table Construction...................................................................................................Precision Ground Cast Iron
Spindle Housing Construction.............................................................................................................. Cast Iron
Column Construction....................................................................................................Cylindrical Ground Steel
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................ Cast Iron
Paint.......................................................................................................................................................... Epoxy
Head Information
Head Swivel.......................................................................................................................................... 360 deg.
G7944 Machine Data Sheet
