ASSEMBLY / DISASSEMBLY
PART NUMBER 145702, REV. B (7/06)
C
16
16
1
3
CUT TO LENGTH
CUT TO LENGTH
TO FACILITY DRAIN
ATTACH THIS END OF THE HOSE
143254 TO THE UNIT INSIDE
CONDENSATE TRAP USING THE
TENSION CLAMP.
6
6
2 " GAP MINIMUM
16
DETAIL C
SCALE 1 : 2
1
5
14
ATTACH HOSE 143254 (3/8" DIAMETER X 30"LONG)
TO THIS PORT USING THE TENSION CLAMP.
16
1 142549 Elbow, 3/4
Item # Part # Description
” Hose Barb
2 141067 Chamber Assembly. Reference only
3 142550 Tee, 3/4” Hose Barb
4 140789 Back Panel - Reference Only.
5 143246 Drain Assembly, Autodrain Kit
6 143250 Hose, long 3/4”ID x 10 ft.
14 127523 Hose Clamp
16 127523 Hose 3/8” ID X 30” Long
