PARTS IDENTIFICATION • VRC-6E
7.1 Cavity Vent Assembly
7
Call 1-800/676-9040 for Technical Support
1
PART NUMBER 145702, REV. B (7/06)
No. Description Qty. Part No.
1* Pressure Relief Valve 1/2 PSI 1 140867
(Remove used plug if needing
to replace)
2 Kit Motor Assembly 1 14688OS
3 Exhaust Assembly 1 141512
8252411esoH4
5 Constant Tension Band 2 127524
6 Clamp, Constant Tension 2 127523
7 Condensate Hose 9” 1 92124
160920
8 Rocker Switch
9 Drain Actuator Shaft 1 141074
10 High Float 1 142689
13 Air Temperature Probe 1 085187
14* Shaft Grip 1 141668
15 Remote Reading 1 141055
16* Overlay (Front Panel Lower) 1 141070
17* Overlay (Front Panel) 1 160523
Dial Thermometer
*Not shown
11 Low Float 1 142689
12 PC Control Board 1 160648
18 Hour meter 1 149295
18
