PARTS IDENTIFICATION • VRC-3E
No. Description Qty. Part No.
1 Cavity Air Temperature Probe 1 085187
2 Probe Protector Assembly 1 074827
3 Compression Nut 1/8” 1 071284
4* Probe Male Fitting 1 071217
5* Remote Reading Thermometer 1 141055
6* Temperature Gauge Bulb Fitting 1 141058
7* Jam Nut 3/4 ”-16 1 141056
8* Fiber Washer 3/4 ” 1 141069
9* Flat Washer 3/4 ” SS 1 114816
10* Compression Fitting 3/8” 1 141057
*Not shown
6.7 Float Assemblies
6
Call 1-800/676-9040 for Technical Support
11
PART NUMBER 145702, REV. B (7/06)
