Groen VRC-3E - 6.3 Door Assembly

PART NUMBER 145702, REV. C (01/07)
CALL 888-994-7636 FOR TECHNICAL SUPPORT
34
PARTS IDENTIFICATION • VRC-3E
No. Description Qty. Part No.
1 Outer Door Panel 1 130895
2 Gasket 1 124849
3 Inner Door Panel 1 130861
4 Truss Head Screws 6 005764
5* Hex Head Screws 2 005608
6 Door Handle 1 129723
7 Door Hinge 1 140755
8 Door Cam 1 074252
9 Latch Assembly 1 140752
10* Door Spacers 4 071206
11* Insulator Board 1 140754
12 Block and Magnet 1 069762
*Not shown
6.3 Door Assembly
(130858)
6
Call 1-800/676-9040 for Technical Support
3
PART NUMBER 145702, REV. B (7/06)
