PART NUMBER 145702, REV. C (01/07)
CALL 888-994-7636 FOR TECHNICAL SUPPORT
43
7
PARTS IDENTIFICATION VRC-6E
7
Call 1-800/676-9040 for Technical Support
5
PART NUMBER 145702, REV. B (7/06)
6
Call 1-800/676-9040 for Technical Support
5
PART NUMBER 145702, REV. B (7/06)
PARTS IDENTIFICATION
7.4 Electrical Components 208/240/480 Volts
No. Description Qty. Part No.
160488
121716
144418
096813
069789
005056
119855
148102
106412
003888
012864
097015
160649
160919
160875
160874
119856
1
1
1
1
11
2
4
1
1
1
2
1
1
1
1
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
High Voltage Panel
Transformer, 75VAC
Contactor, 3-Pole
Capacitor Foil 3 Mfd
Screw Hex Slotted Washer Head Cap
Screw Round Head 8-32 1 1/4”
Nut Lock 6-32
Contactor, 3-Pole 30Fla
Mechanical Lug, Ground, #2-#8
Terminal Block 3-Pole
Bushing Snap 11/16” I.D.
Bushing Snap 1“ I.D. x 1-3/8”
Relayboard, Steamer
Fuse Block Assy
Harness, VRC Low Voltage (not shown)
Harness, Steamer High Voltage (not shown)
480Volt Transformer (not shown)
