7
PARTS IDENTIFICATION • VRC-6E
7
Call 1-800/676-9040 for Technical Support
11
PART NUMBER 145702, REV. B (7/06)
No. Description Qty. Part No.
1 Cavity Air Temperature Probe 1 085187
2 Probe Protector Assembly 1 074827
3 Compression Nut 1/8” 1 071284
4* Probe Male Fitting 1 071217
5* Probe Nut 7/16”-28 1 070452
6* Probe Washer 1 071253
7* Fiber Washer 1 071252
8* Probe Fitting 1 071231
9* Remote Reading Thermometer 1 141055
10* Temperature Gauge Bulb Fitting 1 141058
11* Jam Nut 3/4”-16 1 141056
12* Fiber Washer 3/4” 1 141069
13* Flat Washer 3/4” SS 1 114816
14* Compression Fitting 3/8” 1 141057
*Not shown
7.7 Float Assemblies
