8 Installation
The new generation dataloggers are connected to the USB port of the inverter, the port on
the inverter is indicated as 'USB'.
Before you can connect the data logger to the inverter, you must first loosen the cap on the
inverter, you do this by turning the cap counterclockwise. Then insert the RF-stick into the
USB port and turn the ring clockwise until the arrow on the ring is on the front.
Connect the Shinelanbox to your internet modem with the supplied network cable and plug
the supplied power adapter into a power outlet.
If everything is connected correctly, the lights will light up as follows:
Constant
Constant
Flashes 1 time every 3 seconds (when connected to 1 inverter)
Off
9 Data logger status and recordings
If you cannot monitor the inverter in the Shinephone app, it may have different
characteristics. First, check the status lights on the Shinelanbox. Below are the status of
the LEDs and the solutions for the most common problems.
