3
Product Overview
Single Model Parallel Model
6. AC input
7. WiFi/GPRS communication port
8. USB communication port
9. Dry contact
10. PV input
11. Power on/off switch
12. Battery input
13. Parallel communication ports (only for parallel model)
14. Current sharing ports (only for parallel model)
15. AC output
16. Circuit breaker
18.RS485 communication port (for expansion)
17.BMS communication port(support CAN/RS485 protocol)
1. LCD display
2. Status indicator
3. Charging indicator
4. Fault indicator
5. Function buttons

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Growatt SPF 3000TL LVM and is the answer not in the manual?

Growatt SPF 3000TL LVM Specifications

General IconGeneral
ModelSPF 3000TL LVM
Rated Power3000W
Input Voltage230 VAC
Output Voltage230 VAC
Battery Voltage24 VDC
Max PV Input Voltage145VDC
Max Charging Current80A
Peak Efficiency93%
Output Frequency50 Hz/60 Hz
Dimensions330 x 485 x 135 mm
Battery TypeLead-acid or Lithium
CommunicationRS232
MPPT Voltage Range30-115VDC
