Growatt SPH3600 User Manual

Brief Introduction
1.1 Preface
1.2 Target Group
1.3 Product Description
1.4 Safety Instructions
Safety
2.1 Purpose Use
2.2 Safety Measure
2.3 Symbols introduction on the
SPH inverter
Product Description
3.1 Growatt SPH series inverter
3.2 Label Explanation
3.3 Size and weight
3.4 The advantage of the unit of
Growatt SPH
Unpacking
list
1
2
3
4

Growatt SPH3600 Specifications

General

Model	SPH3600
Type	Hybrid Inverter
Rated Power	3600 W
Max PV Input Voltage	550 V
Number of MPPTs	2
Max Input Current per MPPT	11 A
Nominal DC Voltage	360 V
Nominal AC Power	3600 W
Max AC Current	16 A
Nominal AC Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60 Hz
THDi	<3%
Max Efficiency	97.5%
DC Switch	Yes
Protection Degree	IP65
Battery Voltage Range	42 V - 59 V
Communication Interfaces	RS485, WiFi
Max AC Power	3600W
Euro Efficiency	97.0%
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
