Growatt SPH3600 User Manual

MC 4 specification:
12.2 DC input terminal parameter
2.5mm /14AWG
2
4mm /12 AWG
2
6mm /10 AWG
2
10mm /8AWG
2
Rated current
(90℃environment)
Nominal system
voltage
Contact resistance
Protection grade
32A 40A
44A
65A
600V DC(UL)
600V DC(TUV)
0.25mΩ（model）
IP 68
Socket contact materials
Insulation materials
Ambient temperature range
Wire stripping length
Copper, tin
Thermoplastics UL94 V-0
-40℃ to +90℃
Cable casing diameter
4.5 to 7.8mm(3/16: to 5/16”)
7.0mm(9/32)
Model
Specifications
Growatt
SPH3000
Growatt
SPH3600
Growatt
SPH4000
Growatt
SPH4600
Growatt
SPH5000
Growatt
SPH6000
Display
Interfaces: RS485/
USB /CAN/Wi-
Fi/GPRS
Warranty: 5 years
/ 10 years
Certificates and
approvals
BAT connection
Screw Screw Screw Screw Screw Screw
LCD LCD LCD LCD LCD LCD
yes /opt yes /opt yes /opt yes /opt yes /opt yes /opt
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
58
57
12.4 Appendix
The following chart is the energy storage machine optional appendix list, if there is a
need please contact the Growatt New Energy Technology Co., Ltd or dealer orders.
Name
Shine Wi-Fi-S
Shine 3G
SP-CT
Single phase meter
three phase meter
Description
Used for data record in EU
COM interface
COM interface
Wireless meter sensor
RS485 meter sensor
RS485 meter sensor
Used for data record in Australia
GROWATT P/N
MR00.0005900
MR00.0006100
MR00.0008600
MR00.0004700
MR00.0006700
MR00.000XXXX
MR00.000XXXX
12.3 Torque
Upper cover screws
Shell and RS232screws
Dc connector
M6 screwdriver
1.3Nm(10.8 1bf.in)
0.7Nm(6.2 1bf.in)
1.8Nm(16.0 1bf.in)
2Nm(18 1bf.in)
Grounding screw
2Nm(18 1bf.in)
Shine link

Growatt SPH3600 Specifications

General

Model	SPH3600
Type	Hybrid Inverter
Rated Power	3600 W
Max PV Input Voltage	550 V
Number of MPPTs	2
Max Input Current per MPPT	11 A
Nominal DC Voltage	360 V
Nominal AC Power	3600 W
Max AC Current	16 A
Nominal AC Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60 Hz
THDi	<3%
Max Efficiency	97.5%
DC Switch	Yes
Protection Degree	IP65
Battery Voltage Range	42 V - 59 V
Communication Interfaces	RS485, WiFi
Max AC Power	3600W
Euro Efficiency	97.0%
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
