Growatt SPH5000 User Manual

53
11.1 Dismantling the energy storage
1. Disconnect the storage machine such as mentioned in section 7.
2. Disconnect the upper cable of SPH inverter.
watch out the SPH’s shell heat and prevent to scald
wait 20 minutes until the SPH cooling and then to disassembly!
3. Unscrew all the connecting cable.
4. Unscrew the radiator and wall-mounted anchor screw and then take down the
machine from wall .
11.2 Packing the SPH inverter
Usually placed SPH inverter in the packing box with tape sealing, If the SPH inverter
cannot reoccupy, You can choose a cheap carton for packaging. Carton requirements
must meet the size of the inverter and can support energy storage machine overall
weight.
11.3 Storing SPH inverter
Store SPH inverter in a dry place where ambient temperatures are always between
- 25°C and +60°C
11.4 Disposing of the SPH inverter
Do not dispose of SPH inverter together with household
waste. Please accordance with the disposal regulations for
electronic waste which apply at the installation site at that
time. Ensure that the old unit and, where applicable, any
accessories are disposed of in a proper manner.
11 Decommissioning
12Product Specification
12.1 Growatt SPH series energy storage machine product
specification
Rated AC output
power
54
Model
Specifications
Growatt
SPH3000
Growatt
SPH3600
Growatt
SPH4000
Growatt
SPH4600
Growatt
SPH5000
Growatt
SPH6000
3000W
3680W
4000W
4600W
4999W
6000W
Input data(DC)
Max.
recommended PV
power(for module
STC)
Max. DC voltage
Start voltage
PV voltage range
MPP work voltage
range/ nominal
voltage
Full load dc
voltage range
Max. input current
of tracker A/
tracker B
Output (AC)
3300W/
3300W
3300W/
3300W
3300W/
3300W
4000W/
4000W
4000W/
4000W
4000W/
4000W
550V
150V
550V
150V
550V
150V
550V
150V
550V
150V
550V
150V
120V-550V
150V-550V
/360V
275V-440V
12A/12A 12A/12A 12A/12A 12A/12A 12A/12A 12A/12A
2/1
3000VA
16A
230V ;
180Vac-
280Vac
50/60,±5Hz
1
0.8leading
…0.8
lagging
0.8leading
…0.8
lagging
0.8leading
…0.8
lagging
0.8leading
…0.8
lagging
0.8leading
…0.8
lagging
0.8leading
…0.8
lagging
1 1 1 1 1
230V ;
180Vac-
280Vac
230V ;
180Vac-
280Vac
230V ;
180Vac-
280Vac
230V ;
180Vac-
280Vac
230V ;
180Vac-
280Vac
3680VA
16A
4000VA
22A
4600VA
22A
5000VA
22A
6000VA
27A
2/1 2/1 2/1 2/1 2/1
275V-440V 275V-440V 340V-440V 340V-440V 340V-440V
150V-550V
/360V
150V-550V
/360V
150V-550V
/360V
150V-550V
/360V
150V-550V
/360V
120V-550V 120V-550V 120V-550V 120V-550V 120V-550V
Number of
independent MPP
trackers / strings
per MPP tracker
Max. AC apparent
power
Max. output
current
AC nominal
voltage; range
AC grid
frequency; range
Phase factor at
rate power
Displacement
power factor,
configurable*

Growatt SPH5000 Specifications

General

Model	SPH5000
Type	Hybrid Inverter
Rated Power	5000 W
Max. DC Voltage	550 V
Max. Output Current	22 A
Weight	25 kg
Max. DC Power	6000 W
Start Voltage	150 V
Nominal DC Voltage	360 V
Number of MPP Trackers	2
AC Nominal Power	5000 W
Max. AC Apparent Power	5000 VA
AC Nominal Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60Hz
Total Harmonic Distortion (THDi)	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Injection Current	<0.5% In
Switching Time	<10 ms
Max. Charge/Discharge Power	5000 W
Max. Charge/Discharge Current	100 A
Protection degree	IP65
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
Communication with BMS	CAN
Operating Temperature Range	-25°C to 60°C
MPPT Voltage Range	120 V - 550 V
