Growatt SPH5000 User Manual

42-59Vdc
the type of product
PV input data
Max input power
PV input range
Number of input strings
Max input current per string
AC output data
Max AC apparent power
Max AC output current
AC nominal voltage
Power factor
Stand alone
Rated AC output power
Rated output voltage
Battery data
Battery voltage range
Max charge and discharge current of
battery
Environment
Operating temperature range
Degree of protection
Certificates and approvals
Growatt SPH6000
4000W/4000W
120-550Vdc
2/1
12A
6000VA
27A
230V,50/60Hz
0.8 leading~0.8 lagging
3000W
230V,50/60Hz
66A
Lead battery and lithium battery
-25℃~+60℃
IP 65
G83,G59,AS4777,CEI
0-21,CE,IEC62109,AS/NZS
3100,VDE
0126-1-1,VDE-AR-N4105
type of battery
10
Description of label:
3.3 Size and weight
3.4 The advantage of the unit of Growatt SPH
Features below:
·All in one design. Can improve self consumption, back up and also pinch the valley.
·Smart management,work mode can be set.
·Safe battery used.
·Easy installation.
·Max efficiency 97.5%.
·Two mpp tracker input.
Growatt SPH
A(mm)
weight（kg）
450 565 180
B(mm)
C(mm)
27
9
Chart 3.1

Growatt SPH5000 Specifications

General

Model	SPH5000
Type	Hybrid Inverter
Rated Power	5000 W
Max. DC Voltage	550 V
Max. Output Current	22 A
Weight	25 kg
Max. DC Power	6000 W
Start Voltage	150 V
Nominal DC Voltage	360 V
Number of MPP Trackers	2
AC Nominal Power	5000 W
Max. AC Apparent Power	5000 VA
AC Nominal Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60Hz
Total Harmonic Distortion (THDi)	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Injection Current	<0.5% In
Switching Time	<10 ms
Max. Charge/Discharge Power	5000 W
Max. Charge/Discharge Current	100 A
Protection degree	IP65
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
Communication with BMS	CAN
Operating Temperature Range	-25°C to 60°C
MPPT Voltage Range	120 V - 550 V
