Growatt SPH5000 User Manual

MC 4 specification:
12.2 DC input terminal parameter
2.5mm /14AWG
2
4mm /12 AWG
2
6mm /10 AWG
2
10mm /8AWG
2
Rated current
(90℃environment)
Nominal system
voltage
Contact resistance
Protection grade
32A 40A
44A
65A
600V DC(UL)
600V DC(TUV)
0.25mΩ（model）
IP 68
Socket contact materials
Insulation materials
Ambient temperature range
Wire stripping length
Copper, tin
Thermoplastics UL94 V-0
-40℃ to +90℃
Cable casing diameter
4.5 to 7.8mm(3/16: to 5/16”)
7.0mm(9/32)
Model
Specifications
Growatt
SPH3000
Growatt
SPH3600
Growatt
SPH4000
Growatt
SPH4600
Growatt
SPH5000
Growatt
SPH6000
Display
Interfaces: RS485/
USB /CAN/Wi-
Fi/GPRS
Warranty: 5 years
/ 10 years
Certificates and
approvals
BAT connection
Screw Screw Screw Screw Screw Screw
LCD LCD LCD LCD LCD LCD
yes /opt yes /opt yes /opt yes /opt yes /opt yes /opt
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
CE,IEC621
09,G83 VD
E0126-1-1
,G59,AS4
777, AS/N
ZS 3100,
CEI 0-21
VDE-AR-N
4105
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
yes /yes /
opt/opt/
opt
58
57
12.4 Appendix
The following chart is the energy storage machine optional appendix list, if there is a
need please contact the Growatt New Energy Technology Co., Ltd or dealer orders.
Name
Shine Wi-Fi-S
Shine 3G
SP-CT
Single phase meter
three phase meter
Description
Used for data record in EU
COM interface
COM interface
Wireless meter sensor
RS485 meter sensor
RS485 meter sensor
Used for data record in Australia
GROWATT P/N
MR00.0005900
MR00.0006100
MR00.0008600
MR00.0004700
MR00.0006700
MR00.000XXXX
MR00.000XXXX
12.3 Torque
Upper cover screws
Shell and RS232screws
Dc connector
M6 screwdriver
1.3Nm(10.8 1bf.in)
0.7Nm(6.2 1bf.in)
1.8Nm(16.0 1bf.in)
2Nm(18 1bf.in)
Grounding screw
2Nm(18 1bf.in)
Shine link

Growatt SPH5000 Specifications

General

Model	SPH5000
Type	Hybrid Inverter
Rated Power	5000 W
Max. DC Voltage	550 V
Max. Output Current	22 A
Weight	25 kg
Max. DC Power	6000 W
Start Voltage	150 V
Nominal DC Voltage	360 V
Number of MPP Trackers	2
AC Nominal Power	5000 W
Max. AC Apparent Power	5000 VA
AC Nominal Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60Hz
Total Harmonic Distortion (THDi)	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Injection Current	<0.5% In
Switching Time	<10 ms
Max. Charge/Discharge Power	5000 W
Max. Charge/Discharge Current	100 A
Protection degree	IP65
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
Communication with BMS	CAN
Operating Temperature Range	-25°C to 60°C
MPPT Voltage Range	120 V - 550 V
