Start-up
47 | 84
BA-118940_en_035_GENODOS
-GP.docx
6.1.2 External actuation
1. Plug the red contact for external actuation into the socket.
2. Set the internal/external control selector to Ext.
6.1.2.1 Actuation by external operational release (timer)
Observe the operation manual for the digital time control (order no.
163 950).
1. Adjust the internal/external control selector in the scale range
Int. – 10 (for GP-../40).
2. Connect the time control.
