Grundfos CIU 501 User Manual

English (GB)
26
Address Register name Description Scale
Multi-B MPC DDD Multi-E model G Multi-E/TPED model H and later MAGNA3-D
00301 Head Actual system head/pressure. 0.001 bar - S S S S ●
00302 VolumeFlow Actual system flow. 0.1 m
3
/h - S S S S ●
00303 RelativePerformance Performance relative to maximum performance. 0.01 % ● ● ● ● ● ●
00304
00305
RESERVED -
00306 DigitalInput Logical value of external digital input signals. Bits ●●●●●●
00307 DigitalOutput Logical value of external digital output signals. Bits ●●●●●●
00308 ActualSetpoint
Actual setpoint, according to control mode.
See register 00104 for scaling description.
0.01 % ● ● ● ● ● ●
00309 MotorCurrent Actual motor current. 0.1 A - - - ● - -
00310
00311
RESERVED -
00312
00313
PowerHI
PowerLO
Total power consumption of the system. 1 Watt ● ● ● ● ● ●
00314 RESERVED -
00315 InletPressure
System inlet pressure, relative to atmospheric
pressure.
Has an offset of -1.000 bar.
0.001 bar S S S - S -
00316 RemotePressure1
Measured pressure 1 at external sensor, relative to
atmospheric pressure.
0.001 bar - S - - S S
00317 Level
Tank level.
Has an offset of -100.00 metres.
0.01 m - S S S S -
00318
00319
RESERVED -
00320 RemoteTemp1 Temperature 1 at external sensor. 0.01 K - S - S S -
00321
…
00324
RESERVED -
00325 AuxSensorInput Auxiliary sensor input. 0.01 % - - - S S -
00326 RESERVED -
00327
00328
OperationTimeHI
OperationTimeLO
Total operating time of the system. 1 hour ● ● ● ● ● ●
00329
00330
TotalPoweredTimeHI
TotalPoweredTimeLO
Total power-on time of the system. 1 hour - - - ● - -
00331 RESERVED -
00332
00333
EnergyHI
EnergyLO
Total energy consumption of the system. 1 kWh ● ● ● ● ● ●
00334
00335
00336
RESERVED -
00337 AmbientTemp Ambient temperature 0.01 K - S - - S -
00338 InletTemp Inlet water temperature. 0.01 K - S - - - -
00339 OutletTemp Outlet water temperature. 0.01 K - S - - - -
00340 TempDifference Differential temperature. 0.01 K - S - - - -
00341 OutletPressure System outlet pressure. 0.001 bar S S S - S -
00342 FeedTankLevel
Tank feed level.
It has an offset of -100.00 metres.
0.01 m - S S - S -
00343 UserSetpoint
Setpoint before modifications.
See register 00104 for scaling description.
0.01 % ● ● ● - ● ●
00344 AnalogueInfluence Setpoint attenuator. 0.01 % ● ● ● - ● ●
00345 NumberOfPowerOns
Number of times the booster system has been
powered on.
Unscaled ● ● ● - - -
00346 SpecificEnergy Specific energy. 0.1 Wh/m
3
-S●-S●
00347 SpecificEnergyAverage Average specific energy. 0.1 Wh/m
3
-S●- - -
