Grundfos CME Safety Instructions And Other Important Information

English (GB)
5
English (GB) Safety instructions
Original safety instructions.
CONTENTS
Page
1. Symbols used in this document
2. System sizing
3. Mechanical installation
1. Symbols used in this document
5
2. System sizing
5
3. Mechanical installation
5
4. Electrical connection
6
5. Startup
6
6. Control panel
6
6.1 Setpoint setting
7
6.2 Start/stop of pump
7
6.3 Resetting of fault indications
7
7. Operating conditions
7
7.1 Ambient temperature
7
7.1.1 Ambient temperature during storage and
transportation
7
7.1.2 Ambient temperature during operation 7
7.2 Installation altitude
8
8. Working on the product
8
8.1 Megging
8
9. Fault finding
9
10. Further product information
10
11. Disposal
10
Warning
Prior to installation, read this
document and the quick guide.
Installation and operation must comply
with local regulations and accepted
codes of good practice.
Warning
The use of this product requires
experience with and knowledge of the
product.
Persons with reduced physical,
sensory or mental capabilities must not
use this product, unless they are under
supervision or have been instructed in
the use of the product by a person
responsible for their safety.
Children must not use or play with this
product.
Warning
If these safety instructions are not
observed, it may result in personal
injury.
Warning
If these instructions are not observed,
it may lead to electric shock with
consequent risk of serious personal
injury or death.
Warning
The surface of the product may be so
hot that it may cause burns or personal
injury.
Caution
If these safety instructions are not
observed, it may result in malfunction
or damage to the equipment.
Note
Notes or instructions that make the job
easier and ensure safe operation.
Warning
The system in which the CME Booster
is incorporated must be designed for
the maximum pump pressure.
Caution
The default setting will cause the pump
not to stop until it reaches its maximum
pressure.
Warning
Before starting work on the product,
switch off the power supply. Make sure
that the power supply cannot be
accidentally switched on.

Grundfos CME Specifications

General

Liquid temperature range	0 °C to +60 °C
Maximum operating pressure	10 bar
Series	CME
Frequency	50/60 Hz
Max Pressure	10 bar
Pump Type	Centrifugal
Material	Stainless steel
Applications	pressure boosting, irrigation
Pumped liquid	Clean water
Approvals	CE
Max Liquid Temperature	60°C
Power Supply	1-phase or 3-phase
