Sensor
Control unit specifications
Operating conditions
Storage
Description D-320-GF1-230 D-320-GF3-230
Connection
1 x Buccaneer 400 Series
1 x Terminal block, stripped wire, AWG 28-12
3 x Buccaneer 400 Series
1 x Terminal block, stripped wire, AWG 28-12
Intended use For use with s::can sensors For use with s::can sensors
Maximum load [W] 7 (constant), <15 (peak) 7 (constant), <15 (peak)
Description D-320-GF1-230 D-320-GF3-230
Housing material Polycarbonate, RAL 9005 Polycarbonate, RAL 9005
Material other Polyamide, Polyurethane, EPDM Polyamide, Polyurethane, EPDM
Weight [kg] 1.3 1.3
Dimensions (WxHxL) [mm] 213 x 185 x 118 213 x 185 x 118
Mains connection
1.5mm^2, 3-wires P/N/PE, fixed installation,
M20 cable-gland entry
1.5mm^2, 3-wires P/N/PE, fixed installation,
M20 cable-gland entry
Mains supply voltage [VAC] 100-240/50-60 Hz 100-240/50-60 Hz
Power consumption (typical) [VA] 33, cos q = 0.66 33, cos q = 0.66
Power consumption (max.) [A]
AC inrush current: < 30
AC current: <0.15
AC inrush current: < 30
AC current: <0.15
Terminal connections
4 x M12 cable-gland entry (one used by flow-
switch)
1 x M16 cable-gland entry
4 x M12 cable-gland entry (one used by flow-
switch)
1 x M16 cable-gland entry
IP rating IP 65 IP 65
Memory [MB] 512, industrial grade SLC 512, industrial grade SLC
Display [mm]
128 x 64 graphical display,
70 x 40 viewing area, trans reflective, white
background
128 x 64 graphical display,
70 x 40 viewing area, trans reflective, white
background
Data transfer
USB host mode support for data transfer with
USB stick, Supports FAT/FAT32
USB host mode support for data transfer with
USB stick, Supports FAT/FAT32
Firmware update
USB stick with FAT/FAT32 and firmware
image.
In field upgradeable
USB stick with FAT/FAT32 and firmware
image.
In field upgradeable
Integrated RTC Uncertainty <2 minutes/month at 25 °C Uncertainty <2 minutes/month at 25 °C
Installation
Permanently connected:
• a switch or circuit-breaker must be
included in the installation;
• it must be suitably located and easily
reached;
• it must be marked as the disconnecting
device for the equipment.
Permanently connected:
• a switch or circuit-breaker must be
included in the installation;
• it must be suitably located and easily
reached;
• it must be marked as the disconnecting
device for the equipment.
Conformity - EMC EN 61326-1:2013 EN 61326-1:2013
Conformity - safety EN 61010-1:2010 EN 61010-1:2010
Conformity - RoHS2 (2011/65/EU) EN 50581:2012 EN 50581:2012
Approvals cTUVus, CE, CSA cTUVus, CE, CSA
Description D-320-GF1-230 D-320-GF3-230
Operating temperature limits [° C] -20 to +45 -20 to +45
Humidity limits [%] 5 to 90, non condensing 5 to 90, non condensing
Maximum altitude [m] 3000 3000
Manual cleaning
(llowed substances)
Cleaning with hand-warm water and mild
detergents, (dish washing soap)
Cleaning with hand-warm water and mild
detergents, (dish washing soap)
Description D-320-GF1-230 D-320-GF3-230
Temperature limits [° C] -20 to +50 -20 to +50
Humidity limits [%] 5 to 90, non condensing 5 to 90, non condensing
