Grundfos Hydro Multi-E Series User Manual

English (GB)
6
5. Type key
Example Hydro Multi -E 2 CRIE 15-3 U7 A- A- A- A- ABCD
Name
System type
E: All pumps with E-motor
Number of main pumps
Pump type
Voltage code
U1: 3 x 380-415, N, PE, 50/60 Hz
U2: 3 x 380-415, PE, 50/60 Hz
U7: 1 x 200-240, PE, 50/60 Hz
U8: 1 x 200-240, N, PE, 50/60 Hz
UJ: 1 x 208-230, PE, 60 Hz
UX: CSU variant (special voltage rating)
Design
A: Systems with breaker cabinet mounted on the system
B: Systems with wall mounted breaker cabinet and 5 m cable
C: Systems with breaker cabinet mounted on the left side.
Starting method
A: E
Material combination
A: Stainless steel manifold, base frame and standard valves
B: Stainless steel manifold, base frame and valves
C: Galvanised steel manifold, base frame and standard valves (CME-A pumps only)
G: Galvanised steel manifold, base frame and standard valves
I: Stainless steel manifold, base frame painted black and standard valves
P: Stainless steel manifold, galvanised steel base frame and standard valves
Drinking water approvals
A: ACS-approved components
B: Belgaqua-approved components
D: DVGW-approved components
K: KIWA-approved components
N: NFS-approved components
V: WRAS-approved components
W: WRAS-approved system
Y: No special approval
Options
A: Standard hydraulics
B: No redundant outlet-pressure sensor
C: Outlet-pressure sensor on each pump
D: Sensor as dry-running protection
E: No dry-running protection
F: Level switch as dry-running protection
G: CIM module included
H: Terminal for dry-running protection
K: No inlet manifold
L: Non-return valves on the inlet side
M: Pressure gauge on inlet side
O: PN 25 pressure rating
S: CSU variant
T: Certificate
U: Undersized motor
X: More than four options
