Grundfos UPM3S Series User Manual

Factory presetting
The pump starts at the factory preset operating mode
fixed in the Grundfos software file (GSC). It is overwritten
after the first personal setting. A customised factory preset
might be requested by the customer for his specific
product specification. The following factory preset options
are available:
UPM3S
UPM3 standard range Factory preset
Variant Size
Max. H nom. [m]
Max. P1 nom.
[W]
Operating panel
PWM A PWM C Constant curve Proportional pressure Constant pressure
A1 A2 A3 C1 C2 C3
CC
1
CC
2
CC
3
PP
1
PP
2
PP
3
AA
PP
CP
1
CP
2
CP
3
AA
CP
FLEX AS XX-60 6 42 ● ●
AUTO XX-60 6 42 ● ● ● ● ● ● ● ● ●
HYBRID XX-60 6 42 ● ● ● ● ● ●
UPM3
UPM3 standard range Factory preset
Variant Size
Max. H nom. [m]
Max. P1 nom.
[W]
Operating panel
PWM A PWM C Constant curve Proportional pressure Constant pressure
A1 A2 A3 C1 C2 C3
CC
1
CC
2
CC
3
PP
1
PP
2
PP
3
AA
PP
CP
1
CP
2
CP
3
AA
CP
FLEX AS
XX-50 5 33 ● ●
XX-70 7 52 ● ●
XX-75 7.5 60 ● ●
AUTO
XX-50 5 33 ● ● ● ● ● ● ● ● ●
XX-70 7 52 ● ● ● ● ● ● ● ● ●
SOLAR
XX-75 7.5 60 ● ● ●
XX-105 10.5 52 ● ● ●
XX-145 14.5 60 ● ● ●
DHW
XX-20 2 11 ● ●
XX-50 5 33 ● ● ● ●
XX-70 7 52 ● ● ● ●
HYBRID
XX-50 5 33 ● ● ● ● ● ●
XX-60 6 52 ● ● ● ● ● ●
UPM3L
UPM3 standard range Factory preset
Variant Size
Max. H nom. [m]
Max. P1 nom.
[W]
Operating panel
PWM A PWM C Constant curve Proportional pressure Constant pressure
A1 A2 A3 C1 C2 C3
CC
1
CC
2
CC
3
PP
1
PP
2
PP
3
AA
PP
CP
1
CP
2
CP
3
AA
CP
FLEX AS XX-75 7.5 75 ● ● ● ●
AUTO XX-70 7 X ● ● ● ● ● ● ● ● ●
HYBRID XX-70 7 X ● ● ● ● ● ●
UPM3
8
25
