Grundfos UPM3S Series User Manual

UPM3(K) SOLAR XX-105 130/180
(GFNKB)
0.0 0.2 0.4 0.6 0.8 1.0
1.2
1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0
Q [m³/h]
Q [m³/h]
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
Q [l/s]
0.0 0.2 0.4 0.6 0.8 1.0
1.2
1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8
3.0
10
20
30
40
50
0
0
20
40
60
80
100
0
2
4
6
8
10
[kPa]
p
[m]
H
TM063651
EEI ≤ 0.20 Part 3
P
L,avg
≤ 22 W
Setting
Max. head
nom
Max. P
1 nom
Curve 1 6.5 m 39 W
Curve 2 8.5 m 45 W
Curve 3 10.5 m 52 W
Pump settings
PWM A PWM C PP CP CC
- 1 - - 3
Electrical data, 1 x 230 V, 50 Hz
Speed
P
1
[W] I
1/1
[A]
Min. 2 0.04
Max. 52 0.52
Technical data
System
pressure
Max. 1.0 MPa (10 bar)
Enclosure
class
IPX4D
Minimum inlet
pressure
0.05 MPa (0.50 bar) at
95 °C liquid
temperature
Motor
protection
No external
protection
needed
Liquid
temperature
2-110 °C (TF110)
Max. 130 °C (60 °C
ambient temperature)
Approval and
marking
VDE, CE
Dimensions
B1 B2
H3
H2H1
L1
L3
TM063879
Pump type
Dimensions [mm]
Connections
[inch]
Weight
[kg]
L1 L3 B1 B2 H1 H2 H3
15-105 130 130 90 72 47 25.5 102 127.5 R 1/2 / G 1 1.8
25-105 130 130 90 72 47 25.5 102 127.5 R 1 / G 1 1/2 1.9
25-105 180 180 90 72 47 25.5 102 127.5 R 1 / G 1 1/2 2.0
PWM speed curves on request.
UPM3
17
99
Data sheets
