The selection of any stimulus will deselect a previously selected stimulus on the
opposite channel if the stimuli are not compatible. Refer to the following table
for the stimuli compatibilities listing:
Valid Stimuli Combinations
Transducer Output Selector
The Transducer pushbuttons allow the easy selection of the transducer for each
stimulus available for Channel 1 and Channel 2. A transducer selection may be
changed at any time.
Valid Transducer Combinations
Routing Output
The Routing pushbuttons determine the routing for the stimulus to the
output transducer selected for Channel 1 and Channel 2. Left/Right
delivers the stimuli from Channel 1 to both the left and right transducers.
Both the Channel 1 and Channel 2 maximum dB HL limits are
appropriately decreased from the non-mixed maximum dB HL limits.
Tone Mic Ext A Ext B
Channel 2 NB Noise Valid Invalid Invalid Invalid
Speech Noise Invalid Valid Valid Valid
White Noise Valid Valid Valid Valid
Ext. A Valid Valid Valid Valid
Ext. B Valid Valid Valid Valid
Phone Bone Speaker Insert
Channel 2 Phone Valid Valid Valid Invalid
Bone Valid Valid Valid Valid
Speaker Valid Valid Valid Valid
Insert Invalid Valid Valid Valid
