12. Parts List
PNEG-750-G2 16" Series II Sweep 131' and 135' Diameter 85
End Bearing Components
End Bearing Components Parts List
Ref # Part # Description
1 GC03385 Caster 2" x 4" x 1/2" Axle (16" Sweeps)
2 GC03480 End Caster Assembly (16" Sweeps)
3 GC03387 Hairpin, 1-15/16" x 1/8" Wire (16" Sweeps)
4 GK1522 Washer Head Pin 1/2" Diameter x 3-1/2" (16" Sweeps)
5 GC03577 Flange Bearing 3" End Cap (16" Sweeps)
6 GC03556 End Stub 3" x 14-7/8" (16" Sweeps)
