GSi Sweep II Series User Manual

12. Parts List
PNEG-750-G2 16" Series II Sweep 131' and 135' Diameter 87
Auger Drive Components Parts List
Ref # Part # Description
1
N/A Motor: XPFC, Class 2 Group F and G
712-3-XP 7.5 HP - 213T Frame
MHC60010X 10 HP - 215T Frame
MHC60015X 15 HP - 254T Frame
MHC60020X 20 HP - 256T Frame
MHC60025X 25 HP - 284T Frame
2
GC09993 Motor Mount Assembly w/ Jack
GC09986 Motor Mount Base Assembly
GC09992 Motor Jack Assembly
3 GC03436 Swivel Caster 1-1/2" x 4"
4
N/A Reducer: w/ CEMA Adapter and Output Shaft
GC11363 115SMTP05-2"
GC09809 115SMTP09-2"
GC11364 203SMTP05-2"
GC09587 203SMTP09-2"
GC11597 207SMTP09-2"
GC09810 115SMTP09-3"
GC09588 203SMTP09-3"
GC09589 207SMTP09-3"
GC09591 215SMTP09-3"
5 N/A Belt
6 GC09770 Belt Guard Assembly, Top
7 GC09764 Belt Guard Assembly, Bottom
8 N/A Sprocket
9 N/A Bushing
N/S GC03654 Motor Cover 39" x 35" x 20"
10 GC09762 Belt Guard Bottom Back Plate
11 GC09759 Belt Guard Bottom Pan
12
N/A Belt Guard Motor Specific Plate
GC09875 184T Frame
GC09876 213/215T Frames
GC09877 254/256T Frames
GC09878 284/286T Frames
GC09879 324T Frame
