12. Parts List

PNEG-750-G2 16" Series II Sweep 131' and 135' Diameter 93

Jack Supports Parts List

Ref # Part # Description Qty

1 GC06974 Caster Wheel 3" x 8" Diameter x 3/4" Axle 1

1.1 S-6638 Bolt, HHCS 3/4"-10 x 5-1/2" ZN Grade 8 1

1.2 S-233 Split Lock Washer, 3/4" ZN 1

1.3 S-234 Hex Nut, 3/4"-10 ZN Grade 5 1

2 GC08507 S2 Sweep Jack Caster Assembly 1

3 S-8441 Jack Clevis Pin 1

4 GC07934 S2 Sweep 7000# Jack Assembly 1

4.1 S-7528 Bolt, HHCS 1/2"-13 x 1-1/2" ZN Grade 5 4

4.2 S-236 1/2" Split Lock Washer ZN 4

4.3 S-7510 1/2"-13 Hex Nut Zinc Grade 2 4

5 GC07839 Jack Mount Assembly 1

5.1 S-8400 Bolt, HHCS 1/2"-13 x 3-3/4" ZN Grade 5 4

5.2 S-236 1/2" Split Lock Washer ZN 4

5.3 S-7510 1/2"-13 Hex Nut Zinc Grade 2 4

6 GC07926 S2 Sweep Jack Mount Plate Assembly 1

7 GC07931 S2 Sweep Jack Truss Assembly - 16" 1

7.1 S-7528 Bolt, HHCS 1/2"-13 x 1-1/2" ZN Grade 5 4

7.2 S-236 1/2" Split Lock Washer ZN 4

7.3 S-7510 1/2"-13 Hex Nut Zinc Grade 2 4

N/S GC08627 BOP: Jack Kit (Contains all above parts less wheel) 1
