GSi Sweep II Series User Manual

12. Parts List
PNEG-750-G2 16" Series II Sweep 131' and 135' Diameter 95
Control Panel Components Pre-June 2010 Parts List
Ref # Part # Description
1 GC06993 Din Rail 12.375"
2 DC-889 Decal, Danger High Voltage
3 756-1953-6 Switch-Bell Alarm Integrated
4 756-1977-5 Protector, Motor Starter, 5.5-8A, Int
5 756-1947-8 Bracket-Link, up to 10 Amp
6 756-1976-7 Relay-9 Amp Integrated
7 GT3-896 Mount-Contact, Auxiliary, 1 N.O./N.C.
8 756-2006-2 Starter-Reversing Kit, Integrated
9 756-1992-4 Protector, Motor Starter, 22-32 Amp, Int
10 756-1949-4 Bracket-Link S2, up to 50 Amp
11 756-2002-1 Contactor S2 32 Amp, Integrated
12 GT3-1002 Mount-Contact, Auxiliary, 1 N.O./N.C., Side
13 D01-0533 Din Rail End Stop
14 E160-1137 Ground Lug
15 C-8018 3 Pole Power Distribution Block
16 GC03676 Fuse Block 2 Pole
17 GC03677 Fuse, 600V Midget TD 1/4 Amp
18 GC07510 AC Current Transducer Socket
19 GC07509 AC Current Transducer
20 GC03673 Transformer, 50 VA 50/60 Hz, 230/380/460
21 GC03679 Fuse, 250V Midget TD 6/10 Amp
22 GC07511 Current Transformer 50:5 Amp
23 S-7605 Terminal Block
