GST100 Intelligent Fire Alarm Control Panel
Installation and Operation Manual
Page 4
Chapter 3 Structure
3.1 Appearance and Internal Structure
GST100 is wall-mounted. Its appearance, internal structure and connection are shown in Fig.
3-1 and Fig. 3-2.
Knockout hole
Fig. 3-1
(Optional)
Speaker
Printer
Main Board
LED Board
LCD
485 Network Board
Interface
Board
Fig. 3-2
3.1.1 Front Panel
The FACP’s front panel consists of LCD, general LEDs, zonal LEDs, Keypad and Printer as
