GTO 2002XLS - 2002 XLS Parts List

4 GTO 2002XLS Instruction Manual © 01.12.12
5. 2002XLS Parts List
BRACKET BOX - HB100
HARDWARE BAG - H101P
Operator Arm (1)
PRO2002ARMXLS
Operator Arm (1)
PRO2000ARMXLS
®
E-Z GATE OPENER
Gate Bracket (2)
Post Pivot Bracket (2)
Post Bracket (4)
Closed Position
Stop Plate (2)
Hairpin Clip (4)
5/16" x 1-3/4" Bolt (2)
3/8" x 2" Bolt (2)
3/8" x 2-3/4" Bolt (4)
3/8" x 8" Bolt (8)
8" Nylon Cable Tie (28)
3/8" Washer (18)
3/8" Lock Washer (14)
5/16" Washer (2)
3/8" x 3/16" Bushing (4)
3/8" Nut (14)
5/16" Nut (2)
2" Screw (10)
3/8" x 1-1/2" Clevis Pin (4)
32’ Power
Cable
6’ Power
Cable
Customer Support
Card (1)
