GTO 2002XLS - Technical Specifications

GTO 2002XLS Instruction Manual © 01.12.12 1
Technical Specifications
GTO/ACCESS SYSTEMS 2002XLS AUTOMATIC GATE OPERATOR
DRIVE
 •Lowfrictionscrewdrive(linearactuator)ratedfor-5˚Fto+160˚F(-21˚Cto+71˚C).UseofGTObatteryheater
FM316 (Not solar compatible) is recommended in extreme cold temperatures
 •Poweredbya12Vmotorwithintegralcasehardenedsteelgearreducer.Motorspeedreducedto395rpm.
 •Maximumopeningarcof110˚.Approximateopeningtime(90˚):15-19seconds,dependingonweightofgate.
POWER
 •Thesystemispoweredbya12Vdc,7.0Ah,sealed,rechargeableacidbattery.
 •Batterychargeismaintainedbya120Vac,14Vacoutputtransformer.
NOTE: The transformer should not be directly connected to any battery. Do not replace fuses with higher
ampere rated fuses; doing so will void your warranty and may damage your control board.
 •One(1)bladestylefuseisratedfor15A.
 •Foroptionalsolarchargingseepage2.
CONTROL
 •GTOmicroprocessor-basedcontrolboardissetforpull-to-opengateinstallations.Jumpercanberemovedto
accommodate an optional kit for push-to-open gates (see Accessory Catalog).
 •Acircuitonthecontrolboardregulatescharging.“Sleepdraw”is15mA;“activedraw”is2to5A.
 •Auto-memorizationofdigitaltransmittercode.
 •GTObuilt-inRFreceivertunedto318MHz.
 •Operatorlengthwithpush-pulltubefullyretractedis33
3
/
4
”, mounting point to mounting point, arm stroke 15”
max.
 •Minimumgatelengthis5ft.
 •Adjustableauto-close(3to120seconds),andstallforcepotentiometers.
 •Powerterminalblockaccommodatesatransformerorsolarpanels(notboth).
 •AccessoryterminalblockfullycompatiblewithGTOpushbuttoncontrols,digitalkeypads,loopsdetectors,etc.
 •Controlboardallowsconnectionofsafetyedgesensorsandphotoelectricsensors.
 •Audioentrapmentalarmsoundsifunitencountersanobstructiontwicewhileopeningorclosing.
 •Directdriveforautomaticgatelock.
OPERATIONAL CAPACITY
 •TheGateCapacityChartshowsapproximatecycles,perday,youcanexpectfromtheGTO/ACCESS2002XLS
Automatic Gate Operator when powered with a transformer. Actual cycles may vary slightly depending upon the
type and condition of gate and installation.
NOTE: BALL BEARING HINGES SHOULD BE USED ON ALL GATES WEIGHING OVER 250 LB.
To determine the number of cycles the gate operator will perform using solar panels, please see the
specifications listed on page 2.
* An operation cycle is one full opening and closing of the gate.
These specifications are subject to change without notice.
Gate Weight
Gate Length
Estimated number of daily cycles, based on use with a transformer and one(1) 12 Volt battery.
16 ft.
14 ft.
12 ft.
5 to10 ft.
65
70
75
80
50 lb.
60
65
70
75
100 lb.
50
55
60
65
150 lb.
N/R
50
55
60
200 lb.
N/R
40
45
50
300 lb.
N/R
N/R
35
40
400 lb.
N/R
N/R
N/R
30
500 lb.
N/R - Not Recommended
SW2002XLS Gate Capacity Chart
