Guardall Pi-8 - 10 Special Keypad Function Keys; Panic Alarm (P); Fire Alarm (F); Medical Alarm (M)

9
10. SPECIAL KEYPAD FUNCTION KEYS
There are four keys at the bottom of your keypad. The function of these keys is explained
below.
10.1 PANIC ALARM (P)
Holding down the P key on the keypad for 1 second activates a PANIC ALARM (if
programmed).
If you have additional FIXED PANIC buttons or REMOTE PANIC buttons, pressing either
of these will also activate a PANIC ALARM.
In all of the above situations a special PANIC REPORTING CODE can be sent to the
monitoring company.
This is a high priority condition so DO NOT use this feature unnecessarily.
If the audible panic option has been programmed, then the sounder, strobe and internal
speaker (if fitted) will activate.
10.2 FIRE ALARM (F)
Holding down the F key on the keypad for 1 second activates a FIRE ALARM (if
programmed).
The sounder, strobe and internal speaker (if fitted) will activate. Fire alarms are always
audible.
The alarm auxiliary output will be triggered.
10.3 MEDICAL ALARM (M)
Holding down the M key on the keypad for 1 second activates a MEDICAL ALARM (if
programmed).
The sounder, strobe and internal speaker (if fitted) will activate. Medical alarms are always
audible.
The alarm auxiliary output will be triggered.
10.4 MODE KEY
Your panel may have been programmed to require the MODE key to be pressed at the
same time as any of the above.
