1. THE KEYPAD AND ITS OPERATION
To ensure correct operation of your security system it is essential to familiarize yourself
with the use of the keypad.
1.1 DESCRIPTION OF THE KEYPAD LEDS
A description of the functions of the various leds on the keypad is given below.
1.1.1 READY LED (RED)
When this is on, the panel is ready to be set. (Note: If a tamper is present this led
will still be on).
1.1.2 TAMPER LED (RED)
When this is on, the tamper circuit is alarmed. The internal speaker may also be
sounding (if fitted).
1.1.3 POWER LED (GREEN)
The led is on when mains power is present.
The led flashes when the mains supply is disconnected and a battery is present.
The led goes off when no power is present (mains or battery).
1.1.4 CIRCUIT LEDs (YELLOW)
There are 8 leds which display the status of each circuit.
CIRCUIT LED CONDITION CIRCUIT STATUS
ON CIRCUIT IS BYPASSED
FLASHING ON/OFF CIRCUIT IS ALARMED
OFF CIRCUIT IS CLEAR
1.2 THE KEYPAD BUZZER
The keypad has an internal buzzer that will sound under the following conditions:
1. When any key is pressed during the entry of codes.
2. Three times in the event of an illegal/incorrect keypad entry.
3. Three times if one or more circuits are alarmed when attempting to set the
control panel.
4. To indicate an AC fail or low battery condition.
5. During entry or exit delays.
